PD10B User Guide

Last updated: 2023-03-09 PDF version


PD10B High-gain balanced photodetector user interface
PD10B user interface
  1. Supply +VCC pin with a voltage between 5.5 V and 9 V. Supply -VCC pin with a voltage between -9 V and -5.5 V. The board is regulated to ±5 V internally. Using more than ±6 V supplies increases power consumption without any significant improvement in supply noise rejection.

  2. Illuminate the photodetectors with a maximum of 1.5 mW optical power per photodiode. The linear output voltage range of the transimpedance amplifier is between -3.6 V and 3.6 V.

  3. The output is available on the SMA connector (50 Ω impedance).
