Variable-gain amplifier
Koheron AMP100 is a ±15 V voltage amplifier with adjustable gain.
| Quantity | Price |
|---|
Resources
Specifications
| AMP100 | |
|---|---|
| Gain, Bandwidth | |
| Gain range | 1.05 to 20 |
| 3 dB bandwidth(gain = 10) | 2 MHz |
| Input | |
| Input-referred voltage noise(1 kHz) | < 3 nV/√Hz |
| Input impedance | 50 Ω |
| Coupling | DC |
| Output | |
| Output voltage range(±15 V supply) | -12 V to 12 V |
| Slew rate(high impedance) | 60 V/µs |
| Slew rate(50 Ω) | 10 V/µs |
| Output impedance | 50 Ω |
| Power supply | |
| Positive supply voltage | 5 V to 16 V |
| Negative supply voltage | -16 V to -5 V |
| Quiescent current per rail | 10 mA |
| Other | |
| Outside dimensions | 50 mm x 33 mm x 14 mm |
| Weight | 11 g |
| Operating temperature | -20 °C to 70 °C |
Frequency response
Small signal
Large signal
Input noise
Input voltage noise density measured for a gain of 10.
